舱室浸水报警系统Cabin of Flooding Alarm System

概述 Briel lntroduction

舱室浸水报警系统由舱室报警器和二线制液位传感器组成，用于船舶舱室浸水或液位超限监视，当被监视舱室浸水时发出声光报警信号，来告知船员危险情况，该装置具有断线故障报警，自检及消音功能。

The water ingress alarm system consist of cabin alarm device and a fluid lecel sensor . For ship cabins or liquid level gauge to monitor flooding , audible and visual alarm signal when the monitored compartment flooding , to inform the crew of a dangerous situation , the device has a disconnection fault alarm , self-test and mute functions.

系统组成 :

 System components:

·舱室系统报警器.               ·water ingress alarm device .

·舱室浸水复示器.               ·water ingress repeater .

·液位传感器.                      ·Level sensor .

系统特点：

·采用先进的感应式液位接近传感器，与浮球液位传感器相比，不会因介质存在油污或垃圾而产生卡死现象。

·具有断线报警功能，提高系统的可靠性。

·具有海上导航和通信系统的标准串行接口IEC61162与VDR设备接口。

·具有RS485通讯接口，便于报警信息发送。

注：传感器根据实际情况，可选配开关量液位传感器，如小型浮球液位传感器或防爆型液位传感器。

System Features:

·The use of advanced inductive prodimity sensor level , compared with the float level sensors , not cause of  the presence of oil or garbage generated media stuck phenomenon .

 ·Has broden alarm function , improve system reliability.

·With ship navigation and communications systenms and VDR  IEC61162 standard serial interface device interface .

·Rs485 communication interface , ease of sending alarm information

技术参数  Technique parameter

·电压等级：DC24V±30%  AC220V ±15%

·防护等级：舱室浸水报警器IP23   液位传感器IP67

·功耗：≤10W

·延伸报警接口：无源常开或常闭  触点容量2A/AV220V

·结构形式:舱室浸水报警器可分为嵌入式和壁挂式
